Pressure transmitter for high pressure, series ETX.405

Series ETX.405 Transmitters bring state-of-the-art Silicon-on-Sapphire (SOS) sensor technology to the industrial arena. SOS construction uses very stabile solid state silicon strain gages on a Sapphire carrier which is glass bonded to a titanium diaphragm. This combination provides a very durable transducer which has excellent stability over a wide temperature range.

Specification

Pressure range	0…1.6 bar ro 0…1000 bar
Accuracy	0.5% of F.S
Output signal	4…20mA 0…5V
Operating temp.	-40…85 ℃
Process conn’t	G 1/4”, M12 x 1.25, M14 x 1.5, M20 x 1.5
