The EDA.378 pressure transmitter for railway vehicles is a pressure transmitter applicable to key parts required for railway operation such as railway braking system, compressed air supply, and control.

BFSL ±0.25%FS specification is applied for precise control, and it offers competitive price and quality that can replace the existing imported pressure transmitter.



Specification



Pressure range	0…1.6 bar to 0... 40 bar
BFSL	±0.25 % of F.S / BFSL(Best Fit Straight Line) ​± 0.5% FS included Linearity+Hysteriesis+Repeatability
Electrical connection	mpm plug, M12 plug, Cable type
Signal Output	2-wire : 4…20mA 3-wire : 0…10V, 0...5V, 1...5V
